SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

Hunan Jinlian Cloud Information Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

Series : Button type load cell

Features : Weighing Module Load Cell Mounting Kit

Mounting Type : screw installation

Description : Load Cell Mounting Kit, SC225M

Manufacturing Date Code : 2023-1

Model Number : SC225M

Type : Load Cell

Place of Origin : Guangdong, China

Brand Name : SNC

Use : Force measurement

Theory : strain gauge sensor

Output : mV/V

Product name : SC225M

Capacity : 5-1000N, 0.5Ton-100Ton

Rated output : 2.00±0.005mV/V 4.0±0.005mV/V

Input resistance : 385±15 ohm 765±15 ohm

Output resistance : 350± 3ohm 700± 5ohm

Excitation Voltage : 10VDC

Insulation resistance : 5000 MΩ(50V)

Operating temp. range : -20~+60 ℃

Safe overload : 120%RO

Waterproof Grade : IP67

Packaging Details : 20 units per carton

Port : shenzhen, Hongkong

Supply Ability : 500 Unit/Units per Month

Price : $60-260/units

Contact Now

SC225M Tank Weighing System Compression Weighing Module Load Cell Mounting Kit 2T 10T 20T 30T

SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T
SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T
Product Description

Parameter:

Model

SC225M

Capacity

5-10000N, 0.5Ton-100Ton

Rated output

2.00±0.005mV/V 4.0±0.005mV/V

Accuracy class

0.03%

Nonlinearity

±0.03%FS

Hysteresis

±0.03%FS

Repeatability

±0.02%FS

Creep (30 min)

±0.02%FS

Zero balance

±1.0 %RO

Temp. effect on output

±0.02%FS / 10

Temp. effect on zero

±0.02%FS / 10

Input resistance

385±15 ohm 765±15 ohm

Output resistance

350± 3ohm 700± 5ohm

Insulation resistance

5000 MΩ(50V)

Recommended excitation voltage

10VDC

Compensated temperature range

-10~50

Operating temperature range

-20~+60

Safe overload

120%RO

Load cell material

Alloy steel stainless steel

Waterproof Grade

IP67 IP68

Connecting cable

Φ6x9m

Method of connecting wire

Red- input+, black- Input-. Green- Output+, White- output -


SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

Related Products

SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

Product List

Sensorcon Product Lists
Strain Gauge Load Cell Torque Sensor Display
Linear Strain gauge-AA Wireless sensor Slip ring rotary torque sensor Platform scale display
Half bridge strain gauge-BB,HA,GB,FB Micro load cell Contactless rotary torque sensor Truck scale display
Shear/torque strain gauge-AB,HA Single point load cell Static torque sensor Controller
Full bridge strain gauge-EB, FG,FD Button load cell Meters Junction box
Tee Rosettes strain gauge-CA,BA Shear beam load cell Coupling Big screen display
Round type strain gauge S type load cell Amplifier
Semi-conductor strain gauge Column load cell
Bridge type load cell
Production Process

SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

Company Information

Sensor and Control Co., Ltd. was founded in 2006, mainly engaged in Torque Sensor, Load Cell, Pressure Transducer, Strain Gauges and Weighing Indicators. Since establishment, we insist the guidelines of "Customer Oriented, Quality Focused, Professional Service "All products we supply are environment friendly and has passed RoHS test.

Sensorcon, in accordance with the principle of the introduction of advanced professional ultrasonic gas cleaning, clean Room patches, automatic temperature compensation and detection, high and low temperature testing and thermal experiments, laser welding and printing, CAD design, manufacturing and testing sensor test equipment and production technology ,manufacture all varieties of sensors, high precision, stable performance and also has antiseptic, waterproof, anti-explosion, anti-lightning, etc favored deeply by users.

SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

Packaging & Shipping

SC225M Tank Weighing System Compression Load Cell Mounting Kit with Screw Installation and mV/V Output 2T 10T 20T 30T

FAQ

1.How to place an order ?
Please provide us more details of what you want, such as: application, measurement range, output, accuracy, thread type, electric connector and other related parameters.

2.Does SNCoffer any discount ?
Yes, if you buy large QTY, please contact us, we will give you a big discount.

3.What terms of payment are available ?
We accept T/T, L/C, Trade assurance, Western Union, Paypal, etc.

4.When will you arrange the production ?
We will arrange the production immediately after receiving your payment.

5.How do you ensure good product quality ?
We have a complete quality control system, all of our products are fully checked by IQC, OQC departments

before shipping to our clients.

6.Do you have warranty ?
Yes, we provide 1 year warranty for most of our products. Some products we offer 15month to 24 months warranty.
